Dispatch

Dispatch books freight with a carrier. If you already have a rate, the whole request is one field. Shipwell tenders the shipment, requests the eBOL and PRO number where the carrier issues them, and reports the carrier's answer on one job you poll.

How it works

Create a dispatch job with POST /dispatching/jobs . The response is immediate: a job in PROCESSING with a resource_id .
Shipwell tenders the carrier , and requests the eBOL and PRO number as part of the same booking. See eBOL & PRO Numbers .
Poll the job with GET /dispatching/jobs/{dispatch_job_id} until is_terminal is true .
Keep the resource_id. Tracking, documents and cancellation are all addressed by it.

A job always finishes. A dispatch the carrier never confirms is marked EXPIRED, so is_terminal arrives either way.

Endpoints

Endpoint	What it does
`POST /dispatching/jobs`	Book freight. Returns `201` with the job in `PROCESSING`.
`GET /dispatching/jobs/{dispatch_job_id}`	Read the job and the carrier's answer.
`POST /dispatching/jobs/{resource_id}/cancel`	Cancel a booking, by its `resource_id`.

Book from a rate

This is the usual path. Everything about the shipment comes from the rate, including the stop contacts you sent when rating. If your rating request had a pickup contact with company_name, first_name and phone and a delivery contact with company_name and phone, as the Rating example does, the body is just the rate_id:

Example request

Copy

Copied

curl --request POST 'https://sandbox-api.shipwell.com/dispatching/jobs' \
--header 'Authorization: Token <user-token>' \
--header 'Content-Type: application/json' \
--header 'Idempotency-Key: 9b4f02d8-po-4417-booking' \
--data-raw '{
  "rate_id": "01HZKD9M4TQ4Z8XW0NKZ6RYX4J"
}'

If a rating stop had no contact, or one missing those fields, add the contact for that stop. The carrier needs someone to call for the pickup, and the bill of lading names the consignee:

Example request, adding contacts

Copy

Copied

curl --request POST 'https://sandbox-api.shipwell.com/dispatching/jobs' \
--header 'Authorization: Token <user-token>' \
--header 'Content-Type: application/json' \
--header 'Idempotency-Key: 9b4f02d8-po-4417-booking' \
--data-raw '{
  "rate_id": "01HZKD9M4TQ4Z8XW0NKZ6RYX4J",
  "origin_contact": {"company_name": "Acme", "first_name": "Dock", "last_name": "Team", "email": "dock@acme.com", "phone": "+15125551234"},
  "destination_contact": {"company_name": "Beta Receiving", "first_name": "Receiving", "last_name": "Desk", "email": "rec@beta.com", "phone": "+17135554500"}
}'

Field	Required
`rate_id`	Yes. The `id` of an LTL or VLTL rate that has `charges`. An FTL rate is booked by tendering in the Shipwell app, and sending one here returns `400 unsupported_transportation_mode`. See Booking an FTL rate.
`origin_contact` (`company_name`, `first_name`, `phone`)	Only if the rating pickup stop had no contact with all three. The carrier rejects a pickup with nobody to call.
`destination_contact` (`company_name`, `phone`)	Only if the rating delivery stop had no contact with both. Without it the request is rejected with `400 missing_delivery_contact`.
`origin_planned_window` / `destination_planned_window`	No. Only if the date moved since you rated.
`references` / `notes_for_carrier`	No.

Book without a rate

If you have a negotiated arrangement and no rate to book against, state the shipment in full and name the carrier account. Only an account with COLLECT billing terms can book this way. Sending rate_id together with any of these fields is rejected, because the two shapes can't be mixed.

Example request

Copy

Copied

curl --request POST 'https://sandbox-api.shipwell.com/dispatching/jobs' \
--header 'Authorization: Token <user-token>' \
--header 'Content-Type: application/json' \
--header 'Idempotency-Key: 2e7d6c11-abf-booking' \
--data-raw '{
  "account_id": "01KBZ91QKW3D9VDP5PVY4HWQ1G",
  "provider_code": "ABF",
  "mode": "LTL",
  "stops": [
    {
      "sequence_number": 1,
      "location": {"line_1": "Cincinnati Museum Ctr", "locality": "Cincinnati", "region": "OH", "postal_code": "45203", "country": "US"},
      "contact": {"company_name": "Acme", "first_name": "Dock", "last_name": "Team", "phone": "+16124323789"},
      "requested_window": {"earliest": "2026-12-01T14:00:00Z", "latest": "2026-12-01T22:00:00Z"}
    },
    {
      "sequence_number": 2,
      "location": {"line_1": "4340 Directors Row", "locality": "Houston", "region": "TX", "postal_code": "77092", "country": "US"},
      "contact": {"company_name": "Beta", "first_name": "Receiving", "last_name": "Desk", "phone": "+17136864500"}
    }
  ],
  "handling_units": [
    {
      "quantity": 1,
      "freight_class": "70",
      "weight": {"value": 500, "unit": "LB", "qualifier": "PER_ITEM"},
      "dimensions": {"measurement_type": "DIMENSIONS", "unit": "IN", "length": {"value": 48, "unit": "IN"}, "width": {"value": 40, "unit": "IN"}, "height": {"value": 50, "unit": "IN"}}
    }
  ]
}'

Field	Required
`account_id`, `provider_code`, `mode`	Yes
`stops` (2 or more)	Yes
`requested_window` on the pickup stop (`earliest`, `latest`)	Yes
`contact.company_name`, `first_name` and `phone` on the pickup stop	Yes
`contact.company_name` and `phone` on the delivery stop	Yes
`handling_units` (1 or more)	Yes
`equipment`, `accessorials`, `service_code`, `carrier_rate_id`, `gross_weight`, `total_declared_value`, `customer_reference_number`	No

LTL and VLTL are the modes you can book through the API today.

Read the carrier's answer

Example response (200)

Copy

Copied

{
  "data": {
    "id": "01KBZC9J8Q0000000000000000",
    "resource_type": "dispatch_job",
    "self_link": "https://sandbox-api.shipwell.com/dispatching/jobs/01KBZC9J8Q0000000000000000",
    "status": "COMPLETED",
    "is_terminal": true,
    "created_at": "2026-08-19T15:30:32.591Z",
    "resource_id": "9f2c1b84-6d3a-4c17-9b0e-2f5a7c48d31e",
    "provider_code": "ABF",
    "carrier_name": "ABF Freight",
    "capacity_provider": {"account_id": "01KBZ91QKW3D9VDP5PVY4HWQ1G", "account_name": "ABF - Main"},
    "references": [
      {"qualifier": "BOL_NUMBER", "value": "BOL-77120"},
      {"qualifier": "PICKUP_NUMBER", "value": "PU-448201"},
      {"qualifier": "PRO_NUMBER", "value": "123456789"}
    ],
    "errors": []
  }
}

Status	What it means	What to do
`PROCESSING`	The carrier hasn't answered yet.	Keep polling.
`COMPLETED`	The carrier confirmed the booking. Its pickup number is in `references`, and so is its PRO number when the carrier issued one.	Check `references` for `PRO_NUMBER` (see eBOL & PRO Numbers), then start tracking.
`ERRORED`	The carrier refused the booking. Its reason is in `errors`.	Fix the request, or book another rate.
`EXPIRED`	The carrier never answered.	The tender may still have reached the carrier, so confirm with it before booking the same freight again.
`CANCELLED`	The booking was cancelled with the carrier.
`CANCELLED_INTERNALLY`	Shipwell released the booking, but this carrier can't cancel through Shipwell.	Cancel the freight with the carrier directly.

Note

Send an Idempotency-Key on every booking. Without one, a retried request books again and the carrier gets a second pickup. With one, a retry with the same key and body returns the original dispatch.

Cancel a booking

Cancel with POST /dispatching/jobs/{resource_id}/cancel. The path takes the resource_id from the booking, not the dispatch job id.

The answer is always 200, because whether a carrier can cancel is a fact about the carrier, not an HTTP error:

Example response (200)

Copy

Copied

{
  "data": {
    "resource_id": "9f2c1b84-6d3a-4c17-9b0e-2f5a7c48d31e",
    "carrier_cancellation_requested": false,
    "requires_manual_carrier_cancellation": true,
    "reason": "This carrier does not support dispatch cancellation through Shipwell. You must cancel the load directly with the carrier."
  }
}

carrier_cancellation_requested: true : Shipwell asked the carrier to cancel. Poll the dispatch job for the final status.
requires_manual_carrier_cancellation: true : this carrier can't cancel through Shipwell. The booking is released on Shipwell's side, and reason tells you to cancel with the carrier directly.

Which carriers support cancellation is shown in Supported Carriers.

API reference

Dispatching API reference: every field, with request and response examples and code samples.

Next steps

Once the dispatch is COMPLETED, track the freight and pull its documents, both by the resource_id.
